SPWN-Wall Mounted Lifepo4 Energy Storage Battery 48V 100Ah 4.8kWh
Product Feature:
1.off grid hybrid inverter
2.pure sine wave output
3.all in one(inverter+AC charger+MPPT)
4.2 years warranty
5.CE/FCC/ROHS
6.accpet OEM/ODM
| Model | SDPO-L-3.5k |
| Rated AC input voltage | 110/120VAC |
| Input voltage range | (90Vac-140Vac)+2% |
| Frequency Range | 47+0.3Hz - 55+0.3Hz (50Hz57+0.3Hz - 65+0.3Hz (60Hz) |
| Switch time | 10ms |
| Raled output power | 3.5kW |
| Raled output voltage | 120Vac |
| Output frequency range | 50Hz + 0.3Hz/60Hz + 0.3Hz |
| Output voltage waveform | Pure sine wave |
| Maximum Eficiency | ≥92% |
| Battery voltage | 48vdc |
| Battery type | Lead acid or lithium battery |
| PV operating voltage renge | S60-145vdc |
| Battery voltage range | 40-60Vdc |
| Maximum output power | 4200W |
| PV charging current(can be set) | 0-80A |
| Parallel | no |
| Protection | Undervoltage alarm/shutdown voltage/overvoltage alarm /overvoltage recovery... settable on LCD screen |
| Communication interface | USB/RS485(WiFi/GPRS is optional)Dry node control |
| Size (L*W*D)mm | 378*280*103 |
| Weight (kg) | 75 |
for detailed specification,pls download catalogue or manual
