3KW Modified Sine Wave Power Inverter For Car

3KW Modified Sine Wave Power Inverter For Car

1.It is 300w-3000w 2.modified sine wave output DC-AC 3.1 year warranty 4.12/24/48vdc optional 5.100/110/115/120/220/230vac optional 6.EU/USA/Japan/UK/Australia/Universal socket optional 7.CE/FCC/ROHS/PSE/ETL and pass ISO 8.accept OEM/ODM

0577-62967308

Product Feature:

1.It is 300w-3000w

2.modified sine wave output DC-AC

3.1 year warranty

4.12/24/48vdc optional

5.100/110/115/120/220/230vac optional

6.EU/USA/Japan/UK/Australia/Universal socket optional

7.CE/FCC/ROHS/PSE/ETL and pass ISO

8.accept OEM/ODM

Specification:

Model SGM3000A-121 SGM3000A-122 SGM3000A-241 SGM3000A-242 SGM3000A-481 SGM3000A-482
Rated Power 3000W
Surge Power 6000W(few seconds)
Input Voltage 12VDC 24VDC 48VDC
Output Voltage 110VAC±5% 220VAC±5% 110VAC±5% 220VAC±5% 110VAC±5% 220VAC±5%
USB Port 5V 1A
Frequency 50Hz±3 or 60Hz±3
Output Waveform Modified Sine Wave
Soft Start YES
AC Regulation THD<3%(Linear Load)
DC Voltage Range 10-15.5V 20-31V 40-61V
Low Voltage Alarm 10.5±0.5V 21±0.5V 42±1V
Low Voltage Shut Down 10±0.5V 20±0.5V 40±1V
Low Voltage Recovery 13±0.5V 24±0.5V 48±1V
Over Voltage Shut Down 15.5±0.5V 31±0.5V 61±1V
Over Voltage Recovery 14.8V±0.5V 29V±0.5V 59V±1V
Cooling Way Intelligent Cooling Fan
Protection Battery Low Voltage & Over Voltage, Over Load, Over Temperature, Short Circuit, Reverse Polarity
Working Temperature -10ºC - +50ºC
Net Dimension 410*167*92mm
Inner Box Dimension 480*230*160mm
Meas./Ctn 470*470*335mm/4pcs
N.W./Unit 4.2kg
G.W./Ctn 20KGS
Packing Carton
Warranty 1 Years
File Name Description Size Download
SGM manual 4.99MB
SGM catalogue 5.02MB
CE 0.82MB
ROHS 0.76MB
0MB
