SPWN-Wall Mounted Lifepo4 Energy Storage Battery 48V 100Ah 4.8kWh
Product Feature:
1.off grid hybrid inverter
2.pure sine wave output
3.all in one(inverter+AC charger+MPPT)
4.2 years warranty
5.CE/FCC/ROHS
6.accpet OEM/ODM
| Model | SDPO-L-5k |
| Rated input voltage | 220/230VAC |
| Input voltage range | (170Vac~280Vac)+2%/(90Vac-280Vac)2% |
| Frequency Range | 47+0.3Hz ~ 55+0.3Hz (50Hz)/57+0.3Hz ~ 65+0.3Hz (60Hz) |
| Switch time | 10ms |
| Raled output power | 5kW |
| Raled output voltage | 230VAC |
| Output frequency range | 50Hz + 0.3Hz/60Hz + 0.3Hz |
| Output voltage waveform | Pure sine wave |
| Maximum Eficiency | ＞92% |
| Battery voltage | 48VAC |
| Battery type | Lead acid or lithium battery |
| PV operating voltage renge | 60-145VAC |
| Battery voltage range | 40-60VAC |
| Maximum output power | 4200W |
| PV charging current(can be set) | 0-80A |
| Parallel | no |
| Protection | Undervoltage alarm/shutdown voltage/overvoltage alarm /overvoltage recovery... settable on LCD screen |
| Communication interface | USB/RS485(WiFi/GPRS is optional)Dry node control |
| Size (L*W*D)mm | 498*410*201 |
| Weight (kg) | 12 |
for detailed specification,pls download catalogue or manual
