عربي SPW-B 48V/51.2V 100Ah Power Wall Lithium Energy Storage Battery
12.8V/25.6V 100Ah/150Ah/200Ah
• BMS protection
• Small volume/light weight
• Home energy storage
• Intelligent communication/Optional
SBT Plastic LFP Energy Storage Battery use long working life LiFeP04 battery, and high performance BMs to protect andmanage the battery system, it has wider usage and longer life than traditional battery.
1. LiFePo4 cell class A
2. 50A/100A/150A/200A BMS for charge/di scharge
3. 6000 cycle times@DoD80%
4. IP67 design
5. BT is optional
6. With series/parallel function
7. LCD di splay is optional
※ Energy storage system, control system, alarm system, power system, database
※ Emergency lighting system, emergency power supply, UPS
※ Telecommunications, communication, and fire protection
| Model | SBT-12.8100 | SBT-12.8150 | SBT-12.8200 |
| Standard voltage | 12.8V | 12.8V | 12.8V |
| Standard capacity | 100Ah | 150Ah | 200Ah |
| Standard energy | 1.28kWh | 1.92kWh | 2.56kWh |
| Working voltage | 10-14.6V | 10-14.6V | 10-14.6V |
| Standard charging current | 50A | 50A | 50A |
| Standard discharging current | 100A | 100A | 100A |
| Suggested DOD | 80% | ||
| Cycle life | >6000 cycles | ||
| IP Rating | Ip67 | ||
| Operating temperature for discharge | -20℃-60℃ | ||
| Operating temperature for charge | 0℃-45℃ | ||
| Communication | BT optional | ||
| Display | LCD display optional | ||
| Warranty | 5 years | ||
| Certificate | UN38.3/MSDS/CE/ROHS/FCC | ||
| NW. (kg) | 9.1 | 15 | 17.6 |
| GW. (kg) | 12.2 | 20 | 22 |
| Product size (mm) | 256*165*210 | 532*207*215 | 532*207*215 |
| Package size(mm) | 390*235*310 | 600*275*295 | 600*275*295 |
