100A 12/24V or 36/48V SP Solar Charge Controller

100A 12/24V or 36/48V SP Solar Charge Controller

Model: PWM-SP-100A Voltage: 12/24V or 36/48V Max. Current: 100A

0577-62967308

100A 12/24V or 36/48V SP Solar Charge Controller

Products Specification:

System voltage 12V 24V 48V
 Max Charging current 100A/120A/150A 100A/120A/150A 100A/120A/150A
 DC output power 60A 60A 60A
 No load consume <20mA <30mA <30mA
PV input voltage ≤36V ≤55V ≤100V
 Over voltage protect 16.5V±1% 33.0V±1% 66.0V±1%
Over voltage recovery 15.0V±1% 30.0V±1% 60.0V±1%
 Equal voltage 14.6V±1% (adjustable) 29.2V±1% (adjustable) 58.4V±1% (adjustable)
 Boost voltage 14.4V±1% 28.8V±1% 57.6V±1%
 Float voltage 13.8V±1% 27.6V±1% 55.2V±1%
 Low voltage protect 11.1V±1% (adjustable) 22.2V±1% (adjustable) 44.4V±1% (adjustable)
 Low voltage recovery 12.8V±1% (adjustable) 25.6V±1% (adjustable) 51.2V±1% (adjustable)
Night recognize voltage 3.0V±1% 6.0V±1% 12.0V±1%
 Daytime recognize voltage 7.0V±1% 14.0V±1% 28.0V±1%
 Temperature compensation -4.0mv/ºC/2V
Working temperature -25ºC ~+60ºC
 IP protect IP30
 Cooling way   Cooling fan
Size 216mm*203mm*106.8mm
Weight 2.5kg
