SPWN-Wall Mounted Lifepo4 Energy Storage Battery 48V 100Ah 4.8kWh
1. Pure sine wave output
2. Customize sockets and output voltage of different countries
3. We can provide OEM and ODM service
4. Over-voltage, low voltage, overload, over-temperature, short-circuit protection
5. LED intelligent display
6. One 5V 2.4A fast charging USB and one QC3.0 super-fast charging USB
7. Widely used in all kinds of areas, such as house, camp, school, industry and so on
8. 18650/2.6AH LiO2 battery cell with long life and more circle times
9. Support DC/AC/USB/Type-C four kinds of outputs
10. 25700mah high capacity and keep the long lasting time of your different devices
11. Large output power 300W
12. Stable pure sine wave output
13. High quality battery cell
14. It is our new designed products and the lithium battery is produced by ourselves and we have our own factory
| Model | SIPS-300 | ||||
| Inverter AC output | Ouput Rated Power | 300W | |||
| Ouput Peak Power | 600W | ||||
| Waveform | Pure sine wave | ||||
| Frequency | 50HZ±3 or 60HZ±3 | ||||
| Ouput Voltage | 100V-120VAC±5% | 220V-240VAC±5% | |||
| Output Outlet | Universal（Japan,USA,UK,Europe, Austrial optional) | ||||
| Soft start | yes | ||||
| THD | THD＜3% | ||||
| Protect | Over-voltage, low voltage, overload, over-temperature, short-circuit | ||||
| DC Output | USB -A | 5V 2.4A Fast charging *1 | |||
| USB- B | QC3.0 Super-fast charging *1 | ||||
| Type-c | PD Standard, input/output support 60W：5V3A,9V3A,12V3A,15V3A,20V3A | ||||
| DC Socket(6530) | 12VDC*2 /10A output | ||||
| Cigarette output | DC12V/10A | ||||
| DC Input | Solar Charger（6530） | PWM charger max 15A | |||
| Grid Charger （6530） | Power Adapter 6A | ||||
| AC Input | Grid Input | With UPS function | |||
| LED light | LED Lighting 8W | ||||
| Switch | DC12V output switch，USB switch，Inverter switch，LED light switch（press 3S to on/off） | ||||
| Display | Display type | LED Intelligent display | |||
| Display content | Battery capacity, battery voltage, output voltage, output waveform, frequency, AC load percent, USB status, DC outpu status, LED light status, grid charger working status, solar charging status, blue tooth status | ||||
| Lithium Battery | Battery type | 18650/2.6AH LiO2 battery cell | |||
| Capacity | 308WH | ||||
| Battery Voltage Range | 12.6V-16.8V | ||||
| Min Charging Current | 5A | ||||
| Max continous Charging Current | 25A | ||||
| Max continous Discharge Current | 40A | ||||
| Max Peak Discharge Current | 80A(60S) | ||||
| Cooling Way | Intelligent Fan | ||||
| Working Temperature | （0℃+60℃） | ||||
| Storage Temperature | （-20℃ - 70℃） | ||||
| Humidity | Max 90%，Non-condensing | ||||
| Warantee | 2 Years | ||||
| Size | 187*185*166mm | ||||
